D.8
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
DNP3 Communications
DNP3 in the SEL-2414
40 4 Long Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
41 0 Analog Output Block—All Variations
41 1 32-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 2
e
16-Bit Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
41 3 Short Floating Point Analog Output Block 3, 4, 5, 6 17, 28 129 echo of request
50 0 Time and Date—All Variations
50 1 Time and Date 1, 2 7, 8 index=0 129 07, quantity=1
50 2 Time and Date With Interval
50 3 Time and Date Last Recorded 2 7, 8
51 0 Time and Date CTO—All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 129 07, quantity=1
52 0 Time Delay—All Variations
52 1 Time Delay, Coarse
52 2 Time Delay, Fine 129 7, quantity=1
60 0 All Classes of Data 1, 20, 21 6, 7, 8
60 1 Class 0 Data 1, 20, 21 6, 7, 8
60 2 Class 1 Data 1, 20, 21 6, 7, 8
60 3 Class 2 Data 1, 20, 21 6, 7, 8
60 4 Class 3 Data 1, 20, 21 6, 7, 8
70 1 File Identifier
70 2 Authentication Object
70 3 File Command Object
70 4 File Command Status Object
70 5 File Transport Object
70 6 File Transport Status Object
70 7 File Descriptor Object
80 1 Internal Indications 1, 2 0, 1 index=7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary-Coded Decimal
101 2 Medium Packed Binary-Coded Decimal
101 3 Large Packed Binary-Coded Decimal
110 all Octet String
111 all Octet String Event
112 All Virtual Terminal Output Block 2 6 129
113 All Virtual Terminal Event Data 1 6 129, 130 17, 28
N/A No object required for the following function
codes:13 cold start14 warm start23 delay
measurement
13, 14, 23
a
Supported in requests from master
b
May generate in response to master
c
Decimal
d
Hexadecimal
e
Default variation
f
Qualifier 17 and 28 are not supported for freeze function codes 7, 8, 9, 10.
Tab l e D.5 S EL-241 4 DNP Ob jec t L ist (Sheet 3 of 3)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual. Codes
d
Funct.
Codes
c
Qual. Codes
d
