Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
DNP3 Communications
DNP3 in the SEL-2414
23 5 32-Bit Frozen Counter Event With Time 1 6, 7, 8 129
23 6 16-Bit Frozen Counter Event With Time 1 6, 7, 8 129
23 7 32-Bit Delta Counter Change Event With Time
23 8 16-Bit Delta Counter Change Event With Time
30 0 Analog Input—All Variations 1 0, 1, 6, 7, 8, 17, 28
30 1 32-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 2 16-Bit Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 3 32-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 4
e
16-Bit Analog Input Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 5 Short Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
30 6 Long Floating Point Analog Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
31 0 Frozen Analog Input—All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of Freeze
31 4 16-Bit Frozen Analog Input With Time of Freeze
31 5 32-Bit Frozen Analog Input Without Flag
31 6 16-Bit Frozen Analog Input Without Flag
31 7 Short Floating Point Frozen Analog Input
31 8 Long Floating Point Frozen Analog Input
32 0 Analog Change Event—All Variations 1 6, 7, 8
32 1 32-Bit Analog Change Event Without Time 1 6, 7, 8 129 17, 28
32 2 16-Bit Analog Change Event Without Time 1 6, 7, 8 129, 130 17, 28
32 3 32-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32 4
e
16-Bit Analog Change Event With Time 1 6, 7, 8 129 17, 28
32 5 Short Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32 6 Long Floating Point Analog Change Event 1 6, 7, 8 129 17, 28
32 7 Short Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
32 8 Long Floating Point Analog Change Event
With Time
1 6, 7, 8 129 17, 28
33 0 Frozen Analog Event—All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
33 5 Short Floating Point Frozen Analog Event
33 6 Long Floating Point Frozen Analog Event
33 7 Short Floating Point Frozen Analog Event
With Time
33 8 Long Floating Point Frozen Analog Event
With Time
34 0 Analog Deadband—All Variations
34 1
e
16-Bit Analog Input Reporting Deadband Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 2 32-Bit Analog Input Reporting Deadband Object 1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
34 3 Floating Point Analog Input Reporting Deadband
Object
1, 2 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
40 0 Analog Output Status—All Variations 1 0, 1, 6, 7, 8 129
40 1 32-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 2
e
16-Bit Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
40 3 Short Floating Point Analog Output Status 1 0, 1, 6, 7, 8 129 0, 1, 17, 28
Tab l e D.5 S EL-241 4 DNP Ob jec t L ist (Sheet 2 of 3)
