DNP3 Communications
DNP3 in the SEL-2414
Tab l e D.5 S EL-241 4 DNP Ob jec t L ist (Sheet 1 of 3)
Obj. Var. Description
Request
a
Response
b
Funct.
Codes
c
Qual. Codes
d
Funct.
Codes
c
Qual. Codes
d
1 0 Binary Input—All Variations 1 0, 1, 6, 7, 8, 17, 28
1 1 Binary Input 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
12
e
Binary Input With Status 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
2 0 Binary Input Change—All Variations 1 6, 7, 8
2 1 Binary Input Change Without Time 1 6, 7, 8 129 17, 28
22
e
Binary Input Change With Time 1 6, 7, 8 129, 130 17, 28
2 3 Binary Input Change With Relative Time 1 6, 7, 8 129 17, 28
10 0 Binary Output—All Variations 1 0, 1, 6, 7, 8
10 1 Binary Output
10 2
e
Binary Output Status 1 0, 1, 6, 7, 8 129 0, 1
12 0 Control Block—All Variations
12 1 Control Relay Output Block 3, 4, 5, 6 17, 28 129 echo of request
12 2 Pattern Control Block
12 3 Pattern Mask
20
f
0 Binary Counter—All Variations 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28
20 1 32-Bit Binary Counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 2 16-Bit Binary Counter 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter Without Flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 6
e
16-Bit Binary Counter Without Flag 1, 7, 8, 9, 10 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
20 7 32-Bit Delta Counter Without Flag
20 8 16-Bit Delta Counter Without Flag
21 0 Frozen Counter—All Variations 1 0, 1, 6, 7, 8, 17, 28 129
21 1 32-Bit Frozen Counter 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 2 16-Bit Frozen Counter 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 3 32-Bit Frozen Delta Counter 1 129
21 4 16-Bit Frozen Delta Counter 1 129
21 5 32-Bit Frozen Counter With Time of Freeze 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 6 16-Bit Frozen Counter With Time of Freeze 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 7 32-Bit Frozen Delta Counter With Time of Freeze 1 129
21 8 16-Bit Frozen Delta Counter With Time of Freeze 1 129
21 9 32-Bit Frozen Counter Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 10 16-Bit Frozen Counter Without Flag 1 0, 1, 6, 7, 8, 17, 28 129 0, 1, 17, 28
21 11 32-Bit Frozen Delta Counter Without Flag
21 12 16-Bit Frozen Delta Counter Without Flag
22 0 Counter Change Event—All Variations 1 6, 7, 8
22 1 32-Bit Counter Change Event Without Time 1 6, 7, 8 129 17, 28
22 2
e
16-Bit Counter Change Event Without Time 1 6, 7, 8 129, 130 17, 28
22 3 32-Bit Delta Counter Change Event Without Time
22 4 16-Bit Delta Counter Change Event Without Time
22 5 32-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 6 16-Bit Counter Change Event With Time 1 6, 7, 8 129 17, 28
22 7 32-Bit Delta Counter Change Event With Time
22 8 16-Bit Delta Counter Change Event With Time
23 0 Frozen Counter Event—All Variations 1 6, 7, 8
23 1 32-Bit Frozen Counter Event Without Time 1 6, 7, 8 129 17, 28
23 2 16-Bit Frozen Counter Event Without Time 1 6, 7, 8 129 17, 28
23 3 32-Bit Frozen Delta Counter Event Without Time
23 4 16-Bit Frozen Delta Counter Event Without Time
