D.5
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
DNP3 Communications
DNP3 in the SEL-2414
In response to the delay measurement function code, the SEL-2414 will return a
time delay accurate to within 50 milliseconds.
Object List
Table D.5 lists the objects and variations with supported function codes and qual-
ifier codes available in the SEL-2414. The list of supported objects conforms to
the format laid out in the DNP specifications and includes both supported and
unsupported objects. Those that are supported include the function and qualifier
codes. The objects that are not supported are shown without any corresponding
function and qualifier codes.
Table D.4 SEL-2414 DNP3 Device Profile
Parameter Value
Vendor name Schweitzer Engineering Laboratories
Device name SEL-2414
Highest DNP request level Level 2
Highest DNP response level Level 2
Device function Slave
Notable objects, functions, and/or qualifiers supported Analog Dead-Band Objects (object 34)
Maximum data link frame size transmitted/received (octets) 292
Maximum data link retries Configurable, range 0–15
Requires data link layer confirmation Configurable by setting (preference is to not use link layer
confirmation)
Maximum application fragment size transmitted/received (octets) 2048
Maximum application layer retries None
Requires application layer confirmation When reporting Event Data
Data link confirm time-out Configurable
Complete application fragment time-out None
Application confirm time-out Configurable
Complete Application response time-out None
Executes control WRITE binary outputs Always
Executes control SELECT/OPERATE Always
Executes control DIRECT OPERATE Always
Executes control DIRECT OPERATE-NO ACK Always
Executes control count greater than 1 Never
Executes control Pulse On Always
Executes control Pulse Off Always
Executes control Latch Off Always
Executes control Latch On Always
Executes control Queue Never
Executes control Clear Queue Never
Reports binary input change events when no specific variation requested Only time-tagged
Reports time-tagged binary input change events when no specific
variation requested
Binary Input change with time
Sends unsolicited responses Configurable with unsolicited message enable settings.
Increases retry time (configurable) when a maximum retry
setting is exceeded.
Sends static data in unsolicited responses Never
Default counter object/variation Object 20, Variation 6
Counter roll-over 16 bits
Sends multifragment responses Yes
