F.5IEC 61850 Communications
Logical Nodes
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
METXMMXU1 A.phsA.instCVal.mag Instantaneous, Current Magnitude, Phase A
f
METXMMXU1 A.phsB.instCVal.mag Instantaneous, Current Magnitude, Phase B
f
METXMMXU1 A.phsC.instCVal.mag Instantaneous, Current Magnitude, Phase C
f
METXMMXU1 A.res.instCVal.mag Instantaneous, Current Magnitude, Residual
f
METXMMXU1 A.nseq.instCVal.mag Instantaneous, Current Magnitude, Negative Sequence
f
METXMMXU1 A.phsA.instCVal.ang Instantaneous, Current Angle, Phase A
f
METXMMXU1 A.phsB.instCVal.ang Instantaneous, Current Angle, Phase B
f
METXMMXU1 A.phsC.instCVal.ang Instantaneous, Current Angle, Phase C
f
METXMMXU1 A.res.instCVal.ang Instantaneous, Current Angle, Neutral
f
METMMXU1 PhV.phsA.instCVal.mag Instantaneous, Voltage Magnitude, Phase A
f, g
METMMXU1 PhV.phsB.instCVal.mag Instantaneous, Voltage Magnitude, Phase B
f, g
METMMXU1 PhV.phsC.instCVal.mag Instantaneous, Voltage Magnitude, Phase C
f, g
METMMXU1 PhV.res.instCVal.mag Instantaneous, Voltage Magnitude, Residual
f, g
METMMXU1 PhV.nseq.instCVal.mag Instantaneous, Voltage Magnitude, Negative Sequence
f, g
METMMXU1 PhV.phsA.instCVal.ang Instantaneous, Voltage Angle, Phase A
f, g
METMMXU1 PhV.phsB.instCVal.ang Instantaneous, Voltage Angle, Phase B
f, g
METMMXU1 PhV.phsC.instCVal.ang Instantaneous, Voltage Angle, Phase C
f, g
METMMXU1 PhV.res.instCVal.ang Instantaneous, Voltage Angle, Residual
f, g
METMMXU1 PhV.phsAB.instCVal.mag Instantaneous, Voltage Magnitude, AB
f, g
METMMXU1 PhV.phsBC.instCVal.mag Instantaneous, Voltage Magnitude, BC
f, g
METMMXU1 PhV.phsCA.instCVal.mag Instantaneous, Voltage Magnitude, CA
f, g
METMMXU1 PhV.phsAB.instCVal.ang Instantaneous, Voltage Angle, AB
f, g
METMMXU1 PhV.phsBC.instCVal.ang Instantaneous, Voltage Angle, BC
f, g
METMMXU1 PhV.phsCA.instCVal.ang Instantaneous, Voltage Angle, CA
f, g
METMMXU1 TotW.instMag Instantaneous, Three-Phase Real Power
h
,
i
METMMXU1 W.phsA.instMag Instantaneous, Real Power A
h
,
i
METMMXU1 W.phsB.instMag Instantaneous, Real Power B
h
,
i
METMMXU1 W.phsC.instMag Instantaneous, Real Power C
h
,
i
METMMXU1 TotVAr.instMag Instantaneous, Three-Phase Reactive Power
h
,
i
METMMXU1 VAr.phsA.instMag Instantaneous, Reactive Power A
h
,
i
METMMXU1 VAr.phsB.instMag Instantaneous, Reactive Power B
h
,
i
METMMXU1 VAr.phsC.instMag Instantaneous, Reactive Power C
h
,
i
METMMXU1 TotVA.instMag Instantaneous, Three-Phase Apparent Power
h
,
i
METMMXU1 VA.phsA.instMag Instantaneous, Apparent Power A
h
,
i
METMMXU1 VA.phsB.instMag Instantaneous, Apparent Power B
h
,
i
METMMXU1 VA.phsC.instMag Instantaneous, Apparent Power C
h
,
i
METMMXU1 TotPF.instMag Instantaneous, Three-Phase Power Factor
h
,
j
METMMXU1 PhAPF.instMag Instantaneous, Power Factor A
h
,
j
METMMXU1 PhBPF.instMag Instantaneous, Power Factor B
h
,
j
METMMXU1 PhCPF.instMag Instantaneous, Power Factor C
h
,
j
METXMMXU1 TotW.instMag Instantaneous, Three-Phase Real Power
f
,
i
METXMMXU1 W.phsA.instMag Instantaneous, Real Power A
f
,
i
METXMMXU1 W.phsB.instMag Instantaneous, Real Power B
f
,
i
METXMMXU1 W.phsC.instMag Instantaneous, Real Power C
f
,
i
METXMMXU1 TotVAr.instMag Instantaneous, Three-Phase Reactive Power
f
,
i
METXMMXU1 VAr.phsA.instMag Instantaneous, Reactive Power A
f
,
i
METXMMXU1 VAr.phsB.instMag Instantaneous, Reactive Power B
f
,
i
METXMMXU1 VAr.phsC.instMag Instantaneous, Reactive Power C
f
,
i
METXMMXU1 TotVA.instMag Instantaneous, Three-Phase Apparent Power
f
,
i
Table F.5 Logical Device: MET (Metering) (Sheet 2 of 5)
Logical Nodes Measurand Comment
