Sel 2414 - Page 255

C.9
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL Communications Processors
SEL Communications Processor Example
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
IA 200Bh float
IB 200Dh float
IC 200Fh float
IN 2011h float
IG 2013h float
3I2 2015h float
VA / VAB 2017h float
VB / VBC 2019h float
VC / VCA 201Bh float
VG / (0 for delta) 201Dh float
3V2 201Fh float
P 2021h float
Q 2023h float
S 2025h float
PF 2027h float
FREQ 2029h float
Table C.9 Communications Processor METER Region Map for Both Voltage
(Wye-Connected) and Current Using the SEL
ECT ACI/AVI Combination Input Card
(Sheet 1 of 2)
Item Starting Address Ty pe
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h Int[2]
MONTH 2004h char
DATE 2005h char
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
IAX 200Bh float
IBX 200Dh float
ICX 200Fh float
VA 2011h float
Table C.8 Communications Processor METER Region Map for Both Voltage
(Wye-Delta Connected) and Current Cards (SEL
ECT AVI an d S ELECT 4 CT)
(Sheet 2 of 2)
Item Starting Address Type
