C.10
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL Communications Processors
SEL Communications Processor Example
VB 2013h float
VC 2015h float
VG 2017h float
3V2 2019h float
PX 201Bh float
QX 201Dh float
SX 201Fh float
PFX 2021h float
FREQ 2023h float
Table C.10 Communications Processor SEL-2414
METER Region Map for Both
Voltage (Wye-Connected) and Current Using the SEL
ECT ACI/AVI Combination
Input Card and an Additional Current Card (SEL
ECT 4 CT) (Sheet 1 of 2)
Item Starting Address Ty pe
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h Int[2]
MONTH 2004h char
DATE 2005h char
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
IA 200Bh float
IB 200Dh float
IC 200Fh float
IN 2011h float
IG 2013h float
312 2015h float
IAX 2017h float
IBX 2019h float
ICX 201Bh float
VA 201Dh float
VB 201Fh float
VC 2021h float
VG 2023h float
3V2 2025h float
P 2027h float
Q 2029h float
Table C.9 Communications Processor METER Region Map for Both Voltage
(Wye-Connected) and Current Using the SEL
ECT ACI/AVI Combination Input Card
(Sheet 2 of 2)
Item Starting Address Ty pe
