Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL Communications Processors
SEL Communications Processor Example
Table C.11 shows the list of SEL-2414 meter data available in the SEL communi-
cations processor and the location and data type for the memory areas within D1
(Data Region 1) for a device configured with voltage card only.
Table C.12 shows the list of SEL-2414 meter data available in the SEL communi-
cations processor and the location and data type for the memory areas within D1
(Data Region 1) for a device configured with current card only.
S 202Bh float
PF 202Dh float
PX 202Fh float
QX 2031h float
SX 2033h float
PFX 2035h float
FREQ 2037h float
Table C.11 Communications Processor SEL-2414 METER Region Map for
Voltage Cards Only (Wye-Delta Connected PTs)
Item Starting Address Ty pe
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h Int[2]
MONTH 2004h char
DATE 2005h char
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
VA / VAB 200Bh float
VB / VBC 200Dh float
VC / VCA 200Fh float
VG / (0 for delta) 2011h float
3V2 2013h float
FREQ 2015h float
Table C.12 Communications Processor SEL-2414 METER Region Map for
Current Cards Only (Sheet 1 of 2)
Item Starting Address Ty pe
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h Int[2]
MONTH 2004h char
Table C.10 Communications Processor SEL-2414
METER Region Map for Both
Voltage (Wye-Connected) and Current Using the SEL
ECT ACI/AVI Combination
Input Card and an Additional Current Card (SEL
ECT 4 CT) (Sheet 2 of 2)
Item Starting Address Ty pe
To Next Page
