SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Transformer Monitor Command Summary
COM L B Appends a long report to the summary report of the last 255 records in the communications buffer for
M
IRRORED BITS communications Channel B.
COM S Return a summary report of the last 255 records in the M
IRRORED BITS communications buffer.
COU n Display the values of the SEL
OGIC
®
counters n times.
CPR Display analog signal profile data.
CST Display compressed status report.
CSU Display compressed event summary.
DAT View the date.
DAT dd/mm/yyyy Enter date in DMY format if DATE_F setting is DMY.
DAT mm/dd/yyyy Enter date in MDY format if DATE_F setting is MDY.
DAT yyyy/mm/dd Enter date in YMD format if DATE_F setting is YMD.
EVE n Show event report n with 4 samples per cycle. If n is omitted, most recent report is displayed.
EVE nR Show event report n with raw (unfiltered) 16 samples per cycle analog data and 4 samples per cycle digital
data.
FIL DIR Return a list of files.
FIL READ filename Transfer settings file filename from the device to the PC.
FIL SHOW filename Filename 1 displays contents of the file filename.
GOO k Display transmit and receive GOOSE messaging information. Enter number k to scroll the GOOSE data k
times on the screen.
HEL Display a short description of selected commands.
HIS n Show summary of n latest event reports, where n = 1 is the most recent entry. If n is not specified, all event
report summaries are displayed.
HIS C or R Clear or reset history buffer.
IRIG Force synchronization of internal control clock to IRIG-B time-code input.
MAC Display the MAC address of the Ethernet port (PORT 1).
MAP x y Display DNP3 map for port x, session y.
MET Display instantaneous metering data.
MET A Display analog input metering data.
MET D Display demand and peak demand metering data.
MET E Display energy metering data.
MET F k Display fundamental metering data k times, where k is between 1 and 32767.
MET MATH Display math variable metering data.
MET MAX Display maximum/minimum metering data.
MET RA Display rem
o
te analog metering data.
MET RD Reset demand metering data.
MET RE Reset energy metering data.
MET RM Reset maximum/minimum metering data.
Serial Port Command Command Description
