Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL-2414 Transformer Monitor Command Summary
MET RP Reset peak demand metering data.
MET RTD Display internal and external RTD metering data.
MET TEMP Display internal general purpose RTD/TC metering data.
PRO Display analog signal profile data.
PRO C Clears analog signal profile data.
SER Display all Sequential Events Recorder (SER) data.
SER date1 Display all SER records made on date1.
SER date1 date2 Display all SER records made from dates d2 to d1, inclusive, starting with d2.
SER row1 Display the n most recent SER records starting with record n.
SER row1 row2 Display SER records n2 to n1, starting with n2.
SER C or R Clear/Reset SER data.
SER D Delete SER data.
SHO Show device settings.
SHO DN Show DNP3 settings
SHO F Show front-panel settings.
SHO G Show global settings.
SHO L Show general logic settings.
SHO P n Show serial port settings, where n specifies the port (3, 4, or F); n defaults to the active port if not listed.
SHO R Show report (event and SER) settings.
STA Display device self-test status.
STA S Display SEL
OGIC usage status report.
SUM Display an event summary.
TAR Display Device Word Row 0 (front-panel target LEDs).
TAR n k Display Device Word Row n (n = 0 to 65). Repeat k times (1–32767).
TAR name k Display Device Word Row containing Device Word name. Repeat k times.
TAR R Reset front-panel trip/target LEDs.
TAR … ROW Adding ROW to the command displays the Device Word Row number at the start of each line.
TFE Displays cumulative and individual through-fault event data. The twenty (20) most recent individual events
are displayed.
TFE n Displays cumulative and individual through-fault event data. The n most recent individual events are
displayed, where n = 1 to 1200.
TFE A Displays cumulative and individual through-fault event data. All the most recent individual events are
displayed, up to 1200.
TFE C Clears/resets cumulative and individual through-fault event data.
TFE P Preloads cumulative through-fault event data.
TFE R Clears/resets cumulative and individual through-fault event data.
THE Displays a thermal monitor report that indicates the present thermal status of the transformer.
