SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL-2414 Settings Sheets
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T1THGR1 :=
Ratio Losses (0.1–100.0) T1RATL1
:=
Oil Thermal Time Constant (0.10–20.00 hrs) T1OTR1
:=
Oil Exponent (0.1–5.0) T1EXPN1
:=
Winding Exponent (0.1–5.0) T1EXPM1
:=
Cooling Stage 2 Constants, Transformer 1 (Hidden if ETHERM = N or NUMCS < 2)
TRFR 1 MVA Rating Cooling Stage 2 (1.00–1000.00 MVA) MVA1CS2 :=
Top-Oil Rise/Ambient (0.1–100.0 deg. C) T1THOR2
:=
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T1THGR2
:=
Ratio Losses (0.1–100.0) T1RATL2
:=
Oil Thermal Time Constant (0.10–20.00 hrs) T1OTR2
:=
Oil Exponent (0.1–5.0) T1EXPN2
:=
Winding Exponent (0.1–5.0) T1EXPM2
:=
Cooling Stage 3 Constants, Transformer 1 (Hidden if ETHERM = N or NUMCS < 3)
TRFR 1 MVA Rating Cooling Stage 3 (1.00–1000.00 MVA) MVA1CS3 :=
Top-Oil Rise/Ambient (0.1–100.0 deg. C) T1THOR3
:=
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T1THGR3
:=
Ratio Losses (0.1–100.0) T1RATL3
:=
Oil Thermal Time Constant (0.10–20.00 hrs) T1OTR3
:=
Oil Exponent (0.1–5.0) T1EXPN3
:=
Winding Exponent (0.1–5.0) T1EXPM3
:=
Cooling Stage 1 Constants, Transformer 2 (Hidden if ETHERM ¹ 3 or W)
TRFR 2 MVA Rating Cooling Stage 1 (1.00–1000.00 MVA) MVA2CS1 :=
Hot-Spot Thermal Time Constant (0.01–20.00 hrs) T2THS
:=
Top-Oil Rise/Ambient (0.1–100.0 deg. C)
(Hidden if ETHERM = W)
T2THOR1 :=
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T2THGR1
:=
Ratio Losses (0.1–100.0)
(Hidden if ETHERM = W) T2RATL1 :=
Oil Thermal Time Constant (0.10–20.00 hrs)
(Hidden if ETHERM = W)
T2OTR1 :=
Oil Exponent (0.1–5.0)
(Hidden if ETHERM = W) T2EXPN1 :=
Winding Exponent (0.1–5.0) T2EXPM1
:=
Cooling Stage 2 Constants, Transformer 2 (Hidden if ETHERM ¹ 3 or W and NUMCS < 2)
TRFR 2 MVA Rating Cooling Stage 2 (1.00–1000.00 MVA) MVA2CS2 :=
Top-Oil Rise/Ambient (0.1–100.0 deg. C)
(Hidden if ETHERM = W)
T2THOR2 :=
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T2THGR2
:=
Ratio Losses (0.1–100.0)
(Hidden if ETHERM = W) T2RATL2 :=
Oil Thermal Time Constant (0.10–20.00 hrs)
(Hidden if ETHERM = W)
T2OTR2 :=
Oil Exponent (0.1–5.0)
(Hidden if ETHERM = W) T2EXPN2 :=
Winding Exponent (0.1–5.0) T2EXPM2
:=
Cooling Stage 3 Constants, Transformer 2 (Hidden if ETHERM ¹ 3 or W and NUMCS < 3)
TRFR 2 MVA Rating Cooling Stage 3 (1.00–1000.00 MVA) MVA2CS3 :=
Top-Oil Rise/Ambient (0.1–100.0 deg. C)
(Hidden if ETHERM = W)
T2THOR3 :=
Hot-Spot Cond. Rise/Top Oil (0.1–100.0 deg. C) T2THGR3
:=
