1.11
Date Code 20130214 SEL-2414 Transformer Monitor
Introduction and Specifications
Specifications
Surge Withstand
Capability Immunity: IEC 60255-22-1:2007
2.5 kV common-mode
1.0 kV differential-mode
IEEE C37.90.1-2002,
2.5 kV oscillatory, 4 kV fast transient
Conducted RF Immunity: IEC 60255-22-6:2001, 10 Vrms
IEC 61000-4-6:2006, 10 Vrms
Magnetic Field
Immunity: IEC 61000-4-8:2009
1000 A/m for 3 seconds
100 A/m for 1 minute
EMC Emissions
Conducted Emissions: IEC 60255-25:2000, Class A
Radiated Emissions: IEC 60255-25:2000, Class A
Certifications
ISO 9001: This product was designed and
manufactured under an ISO 9001
certified quality management system.
UL, cUL: UL 508, CSA C22.2 No. 142
CSA: CSA C22.2 No. 61010-1
CE: EMC Directive
Low Voltage Directive
Hazardous Locations
Approvals: Complies with UL1604, CSA 22.2
No. 213, and EN 60079-15.
