E.30
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
2654 A5E 03h, 04h Insulation Aging
Acceleration Factor
(Winding 3)—LW
2655 A5F 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Winding 1)—UW
2656 A60 03h, 04h Rate of Loss-of-Life
(Winding 1)—LW
2657 A61 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Winding 2)—UW
2658 A62 03h, 04h Rate of Loss-of-Life
(Winding 2)—LW
2659 A63 03h, 04h 16 0 100000 0 Rate of Loss-of-Life
(Winding 3)—UW
2660 A64 03h, 04h Rate of Loss-of-Life
(Winding 3)—LW
2661 A65 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Winding 1)—UW
2662 A66 03h, 04h Total Loss-of-Life
(Winding 1)—LW
2663 A67 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Winding 2)—UW
2664 A68 03h, 04h Total Loss-of-Life
(Winding 2)—LW
2665 A69 03h, 04h 16 0 100000 0 Total Loss-of-Life
(Winding 3)—UW
2666 A6A 03h, 04h Total Loss-of-Life
(Winding 3)—LW
2667 A6B 03h, 04h 13 0 999999 0 Time to Total Loss-of-Life
Alarm (Winding 1)—UW
2668 A6C 03h, 04h Time to Total Loss-of-Life
Alarm (Winding 1)—LW
2669 A6D 03h, 04h 13 0 999999 0 Time to Total Loss-of-Life
Alarm (Winding 2)—UW
2670 A6E 03h, 04h Time to Total Loss-of-Life
Alarm (Winding 2)—LW
2671 A6F 03h, 04h 13 0 999999 0 Time to Total Loss-of-Life
Alarm (Winding 3)—UW
2672 A70 03h, 04h Time to Total Loss-of-Life
Alarm (Winding 3)—LW
2673 A71 03h, 04h 1 0 8 0 Thermal Element Condition
(Winding 1)
2674 A72 03h, 04h 1 0 8 0 Thermal Element Condition
(Winding 2)
2675 A73 03h, 04h 1 0 8 0 Thermal Element Condition
(Winding 3)
Table E.15 Modbus Register Map (Sheet 24 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
