TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 19

( leave it on the top or side cover of the control box

housing to avoid operational interruptions with the

Teach Pendant)

(One large calibration plate and one small calibration

plate. Peel the protective wrap off before using.)

(One 8-pin digital I/O cable and one 5-pin analog I/O

cable)

Length: 100 cm

*The IO cables are not used in the standard

assembly of TM Palletizing Operator, but supplied for

connection with customized end-effector.

Control box

Robot Stick

Calibration Plates

IO cables
