Techman Robot TM Palletizing Operator

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 22

In the Teach Pendant carton:

Dimensions: 536mm x 404mm x 446mm

4 x M6X12L type screws

4 x M6 washers

4 x 4mm plugs

1 x Teach Pendant
