120 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.12.2 “MAC Address Filter State Xn” Group
Table 53: WBM “Configuration of MAC Address Filter” Page – “MAC Address Filter State Xn” Group
Enable or disable here the MAC address filter for the
specific interface.
Click [Submit] to apply change. The change is effective immediately.
7.8.1.12.3 “MAC Address Filter Whitelist” Group
Table 54: WBM “Configuration of MAC Address Filter” Page – “MAC Address Filter Whitelist” Group
Displays the MAC address of the relevant list entry.
This displays the MAC mask of the relevant list
entry.
Enable or disable the filter for the relevant list entry
here.
Enter here the MAC address for a new list entry.
You can enter 10 filters.
Enter the MAC mask for the new list entry here.
Enable or disable the filter for the new list entry
here.
Click [Submit] to apply the change. The change is effective immediately.
Click the appropriate [Delete] button to remove an existing list entry. The change
is effective immediately.
Click [Add] to accept a new list entry. You can enter 10 filters. The change is
effective immediately.
