WAGO-I/O-SYSTEM 750 Device Description 29
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
3.2 Labeling
The front labeling includes:
- Device designation
- Name of the display elements, connections and control elements
- Serial number with hardware and firmware version
The side labeling includes:
- Manufacturer's identification
- Connector pin assignment
- Serial number
- Approval information
3.2.1 Manufacturing Number
The serial number indicates the delivery status directly after production.
Figure 2: Marking Area for Serial Numbers
There are two serial numbers in two rows in the side marking. They are left of the
release tab. The first 10 positions in the longer row of the serial numbers contain
version and date identifications.
Example structure of the rows: 0114010101…
01
14
01
01
01
(additional positions)
WW
YY
FW --
HW
FL
-
Calendar
week
Year
Firmware
version
Hardware
version
Firmware
loader
version
Internal information
The row order can vary depending on the production year, only the longer row is
relevant. The back part of this and the shorter row contain internal administration
information from the manufacturer.
