184 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.5.2 “General Configuration” > “Interface xxx” Submenu
This submenu contains the firewall settings on the IP level for the selected
interface.
Table 135: “Firewall” > “General Configuration” > “Interface xxx” Submenu
Menu Item
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. Interface state
Enable or disable the firewall for the selected
interface.
0. Back to …
Back to the higher-level menu
1. Open
The firewall for the selected interface
is disabled.
2. Filtered
The firewall for the selected interface
is enabled.
2. ICMP Policy
Enable or disable the “ICMP echo” protection for the
respective interface.
0. Back to …
Back to the higher-level menu
1. Accept
The “ICMP echo” protection is
disabled.
2. Drop
The “ICMP echo” protection is
enabled.
3. ICMP Limit
You can specify the maximum number of “ICMP
pings” per second.
“0” = “Disabled”
4. ICMP Burst
You can specify the maximum number of “ICMP
echo bursts” per second.
“0” = “Disabled”
5. Telnet
Enable or disable the firewall for the respective
service.
The services themselves must be enabled or
disabled separately on the “Ports and Services”
page.
6. FTP
7. FTPS
8. HTTP
9. HTTPS
10. I/O-CHECK
11. PLC Runtime
12. PLC WebVisu –
direct link (port 8080)
13. SSH
14. TFTP
15. BootP/DHCP
16. DNS
17. Modbus TCP
18. Modbus UDP
19. SNMP
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
