WAGO-I/O-SYSTEM 750 Commissioning 105
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.6 “PLC WebVisu” Page
The settings for the web visualization created in the runtime system are shown
on the “PLC WebVisu” page.
7.8.1.6.1 “Webserver Configuration” Group
Table 38: WBM “PLC WebVisu” Page – “Webserver Configuration” Group
Display Fields
Explanation
e!RUNTIME Webserver
State
This indicates the status (enabled/disabled) of the
e!RUNTIME Webserver.
Default Webserver
Choose here whether the Web-based Management
or web visualization of the runtime system should be
displayed when only entering the IP address of the
controller.
Web-based
Management
The Web-based Management is
displayed.
Web-Visu
The web visualization of the runtime
system is displayed.
Click [Submit] to apply change. The change is effective immediately.
In its default setting, the WBM is called up when only entering the IP address.
To update the display after switching, enter the IP address again in the address
line of the web browser.
To display the web visualization, the Webserver must be enabled (in WBM under
“Ports and Services” -> “PLC Runtime Services”) and there must be a suitably
configured application.
Regardless of the default Web server setting, the WBM can be called up at any
time with “https://<IP address>/wbm” and the Web visualization with
“https://<IP address>/webvisu”.
Possible error messages when calling up the web visualization
The “500 − Internal Server Error” message indicates that the Webserver is not
enabled.
A page with the header “WebVisu not available” means that no application has
been loaded in the controller using web visualization.
