WAGO-I/O-SYSTEM 750 Appendix 299
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
Table 251: DALI Multi-Master Module 753-647 in the "Easy" Mode
Input Process Image
Offset
Byte Designation
Note
High Byte
Low Byte
0
-
S
res.
Status, activate broadcast
Bit 0: 1-/2-button mode
Bit 2: Broadcast status ON/OFF
Bit 1,3-7: -
1
DA4…DA7
DA0…DA3
Bit pair for DALI address DA0:
2
DA12…DA15
DA8…DA11
Bit 1:
Bit set = ON
3
DA20…DA23
DA16…DA19
Bit not set = OFF
4
DA28…DA31
DA24…DA27
Bit 2:
Bit set = Error
5
DA36…DA39
DA32…DA35
Bit not set = No error
6
DA44…DA47
DA40…DA43
Bit pairs DA1 DA63 similar to DA0.
7
DA52…DA55
DA48…DA51
8
DA60…DA63
DA56…DA59
9
GA4…GA7
GA0…GA3
Bit pair for DALI group address GA0:
Bit 1:
Bit set = ON
Bit not set = OFF
10
GA12…GA15
GA8…GA11
Bit 2:
Bit set = Error
Bit not set = No error
Bit pairs GA1 GA15 similar to GA0.
11
-
-
Not used
DA = DALI address
GA = Group address
