264 Use in Hazardous Environments WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
14.1.2 Marking for the United States of America (NEC) and Canada
(CEC)
Figure 54: Marking Example According to NEC
Figure 55: Text Detail – Marking Example According to NEC 500
Table 200: Description of Marking Example According to NEC 500
Marking
Description
CL I
Explosion protection (gas group)
DIV 2
Area of application
Grp. A B C D
Explosion group (gas group)
op temp code T4
Temperature class
