Page #144 background imageLoading...
Page #144 background image
144 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.29 “DHCP Configuration” Page
The settings for the DHCP service are shown on the “DHCP Configuration” page.
7.8.1.29.1 “DHCP Configuration Xn” Group
Table 83: WBM “DHCP Configuration” – “DHCP Configuration Xn” Group
Parameter
Explanation
Service active
Enable or disable the DHCP service for the interface
Xn.
IP Range
Enter here a range of available IP addresses.
Lease time (sec)
Specify the lease time here in seconds. 120
seconds are entered by default.
Static hosts/
Static host n
This displays the static assignments of MAC IDs to
IP addresses. If no assignment was defined, “No
static hosts configured” is displayed.
New static host
Enter here a new static assignment, e.g.,
“01:02:03:04:05:06=192.168.1.20” or
“hostname=192.168.1.20.”
You can enter 10 assignments.
Click on [Submit] to accept the changes. The changes will be effective
immediately.
Click on [Add] to accept a new assignment. The change is effective immediately.
Click on [Delete] to delete an existing assignment. The change is effective
immediately.
