WAGO PFC100 User Manual

102 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.3 “Status Information” Page
The following tables explain the parameters listed on this page:
7.8.1.3.1 “Controller Details” Group
This group displays the properties of the controller.
Table 34: WBM “Status Information” Page – “Controller Details” Group
Parameter
Explanation
Product Description
Controller identification
Order Number
Item number of the controller
License Information
Notification that the CODESYS runtime system is
available
Firmware Revision
Firmware status
7.8.1.3.2 “Network Details Xn” Group(s)
This group displays the network and interface properties of the controller.
If the switch is enabled, one group (“Network Details X1/X2”) is shown for both
connections.
If the switch is disabled, a separate group (“Network Details X1” / “Network
Details X2”) is shown for each connection.
Table 35: WBM “Status Information Page – “Network Details Xn” Group(s)
Parameter
Explanation
State
Status of the ETHERNET interface
(enabled/disabled)
Mac Address
MAC address identifies and addresses the controller
IP Address
Current IP address of the controller and (in brackets)
the reference type (static/bootp/dhcp)
Subnet Mask
Current subnet mask of the controller
