7.8.2.2.2 “Information” > “Network Details” Submenu
In this submenu, the network and interface properties of the controller are
displayed.
If the EHERNET interfaces are operated in “Switched” mode, a common table
(“X1/X2”) is displayed for both connections.
If the EHERNET interfaces are operated in “Separated” mode, an individual table
(“X1” / “X2”) is displayed for each connection.
Table 111: “Information” > “Network Details” Submenu
Parameters
Explanation
State
Status of the ETHERNET interface
(enabled/disabled)
Mac Address
MAC address identifies and addresses the controller
IP Address
Current IP address of the controller and (in brackets)
the reference type (static/bootp/dhcp)
Subnet Mask
Current subnet mask of the controller
To return to the higher-level menu, press [Q] or [Return].
