Page #211 background imageLoading...
Page #211 background image
WAGO-I/O-SYSTEM 750 Commissioning 211
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.12.2 “SNMP” > “SNMP v1/v2c Manager Configuration” Submenu
This submenu contains the SNMP v1/v2c Manager settings.
Table 175: “SNMP” > “SNMP v1/v2c Manager Configuration” Submenu
Parameters
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. Protocol state
Enable or disable the SNMP v1/v2c protocol.
0. Back to …
Back to the higher-level menu
1. Enable
The SNMP v1/v2c protocol is
enabled.
2. Disable
The SNMP v1/v2c protocol is
disabled.
2. Local community name
Specify here the community name for the SNMP
manager configuration (max. 32 characters, no
spaces).
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
7.8.2.12.3 “SNMP” > “SNMP v1/v2c Trap Receiver Configuration” Submenu
This submenu contains settings for the v1/v2c trap receivers.
Table 176: “SNMP” > “SNMP v1/v2c Trap Receiver Configuration” Submenu
Parameters
Explanation
0. Back to …
Back to the higher-level menu
(n). Trap Receiver (n)
Opens a submenu with information on the selected
v1/v2c trap receiver to delete the trap receiver
(n + 1). Add new Trap
Receiver
Opens a series of submenus to create a new v1/v2c
trap receiver
You can enter 10 trap receivers.
The following entries/selections are possible:
IP address of the new trap receiver
(management station)
Community name for the new trap receiver
configuration (max. 32 characters, no spaces)
SNMP version via which the traps are sent
(v1/v2c)
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
