192 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.7.1 “Administration” > “Users” Submenu
This submenu contains settings for the user passwords.
Table 143: “Administration” > “Users” Submenu
Back to the higher-level menu
Enter a new password for the “user” user.
Enter a new password for the “admin” user.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
7.8.2.7.2 “Administration” > “Create Image” Submenu
This submenu contains the selection for creating the image.
In addition to the menu item for the enabled storage medium, the current status is
displayed.
Table 144: “Administration” > “Create Image” Submenu
Back to the higher-level menu
To create an image on the memory card, select this
menu item. Enter the reserved memory size in
another step.
This menu item only appears if the memory card is
inserted.
To create an image on the internal memory, select
this menu item.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
