290 Appendix WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
750-633
The above Counter Module has a total of 5 bytes of user data in both the Input
and Output Process Image (4 bytes of counter data and 1 byte of control/ status).
The following tables illustrate the Input and Output Process Image, which has a
total of 3 words mapped into each image. Word alignment is applied.
The meaning of the output data depends on the set operating mode:
1 Up counter with enable input
2 Up/down counter with U/D input
3 Frequency counter
4 Gate time counter
Table 235: Counter Modules 750-633
Input Process Image
Offset
Byte Designation
Description
High Byte
Low Byte
0
-
S
Status byte
1
D1
D0
Counter Value
2
D3
D2
Output Process Image
Offset
Byte Designation
Description
High Byte
Low Byte
0
-
C
Control byte
1
D1
D0
Counter Setting Value
1,2)
watchdog time
3)
reserved
4)
2
D3
D2
Counter Setting Value
1,2)
reserved
3)
reserved
4)
1,2)
Up counter with enable input, Up /down counter with U / D input
3)
Frequency counter
4)
Gate time counter
750-638,
753-638
The above Counter Modules have a total of 6 bytes of user data in both the Input
and Output Process Image (4 bytes of counter data and 2 bytes of
control/status). The two counter values are supplied as 16 bits. The following
tables illustrate the Input and Output Process Image, which has a total of 4 words
mapped into each image. Word alignment is applied.
Table 236: Counter Modules 750-638, 753-638
Input Process Image
Offset
Byte Designation
Description
High Byte
Low Byte
0
-
S0
Status byte of Counter 1
1
D1
D0
Counter Value of Counter 1
2
-
S1
Status byte of Counter 2
3
D3
D2
Counter Value of Counter 2
