WAGO PFC100 User Manual

42 Device Description WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
3.8 Technical Data
3.8.1 Mechanical Data
Table 12: Technical Data – Mechanical Data
Width
50 mm
Height (from upper edge of DIN 35 rail)
65 mm
Length
100 mm
Weight
114 g
3.8.2 System Data
Table 13: Technical Data – System Data
CPU
Cortex A8, 600 MHz
Operating System
Real-time Linux
®
4.9.47-rt37
(with RT Preemption Patch)
MicroSD card slot
Push-push mechanism,
sealable cover lid
Type of memory card
microSD up to 32 Gbytes
(All guaranteed properties are valid only
in connection with the WAGO
758-879/000-3102 memory card.)
3.8.3 Power Supply
Table 14: Technical Data – Power Supply
Power supply
24 VDC (-25 % … +30 %)
Max. input current (24 V)
550 mA
Power failure time acc. IEC 61131-2
Depending on external buffering
Total current for I/O modules (5V)
700 mA
Isolation
500 V system/supply
Buffer for system power supply!
The system power supply must be buffered to bridge power outages. As the
power demand depends on the respective node configuration, buffering is not
implemented internally.
To achieve power outages of 1 ms to 10 ms according to IEC61131-2, determine
the buffering appropriate for your node configuration and structure it as an
external circuit.
