104 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.5 “General PLC Runtime Configuration” Page
The settings for the boot project created with the programming software are given
on the “General PLC Runtime Configuration” page.
7.8.1.5.1 “General PLC Runtime Configuration” Group
Table 37: WBM “General PLC Runtime Configuration” Page – “General PLC Runtime Configuration”
Group
Parameters
Explanation
PLC runtime version
Select here the PLC runtime system to be enabled.
None
No runtime system is enabled.
e!RUNTIME
e!RUNTIME runtime system is
enabled.
Home directory on memory
card enabled
Define if the home directory for the runtime system
should be moved to the memory card.
Disabled
The home directory is stored in the
internal memory.
Enabled
The home directory is moved to the
memory card.
All data is deleted when switching the runtime system!
The runtime system’s home directory is completely deleted when switching the
runtime system!
Insert a memory card before switching the home directory!
When moving the home directory to the memory card, insert a memory card
formatted to support file system. Only the first partition of a memory card can be
accessed at /media/sd and can be used as the home directory.
Perform a reset before switching the home directory!
Stop IEC-61131 applications in use before switching the home directory of the
runtime system.
Restore the device to its initial state using the “Reset” function. Any boot project
is deleted.
Click [Submit] to apply the change.
The runtime system change is effective immediately.
The home directory change takes effect after the next restart.
