214 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
</dg_
7.8.3 Configuration using “WAGO Ethernet Settings”
The “WAGO Ethernet Settings” program enables you to read system information
about your controller, make network settings and enable/disable the Web server.
Observe the software version!
To configure the controller, use at least Version 6.4.1.1 dated 2015-06-29 or
newer of “WAGO Ethernet Settings”!
You must select the correct COM port after starting “WAGO Ethernet Settings”.
Figure 35: “WAGO Ethernet Settings” – Start Screen
For this, click “Settings” and then “Communication”.
In the “Communication settings” window that then opens, adapt the settings to
your needs.
