WAGO-I/O-SYS
TEM 750
Appendix
283
750
-
8100
PFC100; 2E
TH; ECO
Manual
Version 1.6.0, vali
d from F
W
Version 03.02
.02(14)
Table
225
: 2-Channel Analog Input Modules HART
Input Process Image
Offset
Byte Destination
Description
High Byte
Low Byte
0
D1
D0
Measured Value Channel 1
1
D3
D2
Measured Value Channel 2
Table
226
:: 2 Channel Analog Input Modules HART + 6 bytes M
ailbox
Input Process Image
Offset
Byte Destination
Description
High Byte
Low Byte
0
Internal Use
S0
Internal used
Status byte
1
MBX_RES
MBX_RES
Response data from mailbox
2
MBX_RES
MBX_RES
3
MBX_RES
MBX_RES
4
D1
D0
Measured Value Channel 1
5
D3
D2
Measured Value Channel 2
Output Process Image
Offset
Byte Destination
Description
High Byte
Low Byte
0
-
C0
Control byte
1
MBX_REQ
MBX_REQ
Request data from mailbox
2
MBX_REQ
MBX_REQ
3
MBX_REQ
MBX_REQ
4
-
-
Not used
5
-
-
15.1.3.4
4 Channel A
nalog Input Modules
7
50
-
45
0
,
-453, -455, -457, -459, -460
,
-463, -464
(4-Channel Opera
tion), -
468,
-471, -468, (and all
variation
s),
753
-453, -455, -457, -45
9
Table
227
: 4 Channel Analog Input Modules
Input Process Image
Offset
Byte Destination
Description
High Byte
Low Byte
0
D1
D0
Measured Value Channel 1
1
D3
D2
Measured Value Channel 2
2
D5
D4
Measured Value Channel 3
3
D7
D6
Measured Value Channel 4
282
284
