WAGO-I/O-SYSTEM 750 Commissioning 111
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.9 “Ethernet Configuration” Page
The settings for Ethernet TCP/IP are located on the “Ethernet Configuration”
page.
7.8.1.9.1 “Switch Configuration” Group
Table 44: WBM “Ethernet Configuration” Page – “Switch Configuration” Group
Enable or disable the switch.
Both interfaces are operated with one
IP address.
Each interface is operated with its own
IP address.
Enable or disable the mirroring of the data traffic
between the ports.
Both Ethernet ports operating normally.
The entire data traffic between X1 and
the PFC system is mirrored at port X2.
The entire data traffic between X2 and
the PFC system is mirrored at port X1.
Set here the aging time of unused entries in the list
of MAC addresses with a port assignment to
external network stations.
This field is only enabled in “switched” mode. Fast
aging is only effective in this mode.
An unused address entry becomes
obsolete after 200 seconds.
An unused address entry becomes
obsolete after 800 microseconds.
Set here the broadcast limit for protection against
overloads.
No limitation of broadcast packets.
Limitation of incoming broadcast
packets to the selected percentage of
the total possible data throughput
(10/100Mbit).
Set here the basic limitation of the incoming data
traffic.
No limitation of the incoming data traffic
Limitation of the incoming data traffic to
the entered value
Click [Submit] to apply the change. The change is effective immediately.
