WAGO-I/O-SYSTEM 750 Commissioning 183
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.5.1 “Firewall” > “General Configuration” Submenu
This submenu contains the general settings for the firewall.
Table 134: “Firewall” > “General Configuration” Submenu
Menu Item
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. Firewall enabled entirely
Enables/disables the complete functionality of the
firewall.
0. Back to …
Back to the higher-level menu
1. Enable
Firewall is enabled.
2. Disable
Firewall is disabled.
2. ICMP echo broadcast
protection
Enable or disable the “ICMP echo broadcast”
protection.
0. Back to …
Back to the higher-level menu
1. Enable
“ICMP echo broadcast” protection is
enabled.
2. Disable
“ICMP echo broadcast” protection is
disabled.
3. Max UDP connections
per second
You can specify the maximum number of UDP
connections per second.
“0” = “Disabled”
4. Max TCP connections
per second
You can specify the maximum number of TCP
connections per second.
“0” = “Disabled”
5. Interface VPN
Opens a submenu with firewall settings on the IP
level for the selected interface
6. Interface WAN
7. Interface X1
8. Interface X2
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
Click [<OK>] to apply the entry.
Click [<Abort>] to discard the entry.
