WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Diagnostics 249
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
10.2.4 Meaning of Blink Codes and Procedures for
Troubleshooting
This section describes the diagnostics presented as blink codes via the MS
LEDs.
If the diagnostics cannot be cleared by the measured specified for them, contact
WAGO support. Be ready to explain to them the blink code that is displayed.
Phone: +49 571 887 44 55 5
Fax: +49 571 887 84 45 55
E-mail: support@wago.com
Table 196: Overview of MS-LED Error Codes
Error Code
Explanation
1
Configuration error
Table 197: Error Code 1, Explanation of Blink Codes and Procedures for Troubleshooting
Error
Argument
Cause
Remedy
5
Error when
synchronizing the
controller
configuration with the
local bus
- Check the information of the
connected I/O modules in the
CODESYS controller configuration.
- Adjust this to match the I/O module
that is actually inserted.
- Recompile the project.
- Reload the project into the controller.
