WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Appendix 307
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
15.1.6 System Modules
15.1.6.1 System Modules with Diagnostics
750-606
The modules provide 2 bits of diagnostics in the Input Process Image for
monitoring of the internal power supply.
Table 260: System Modules with Diagnostics 750-606, -611
Input Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Diagnostics
bit S_out
Diagnostics
bit S_in
750-610, -611
The modules provide 2 bits of diagnostics in the Input Process Image for
monitoring of the internal power supply.
Table 261: System Modules with Diagnostics 750-610, -611
Input Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Diagnostics
bit S 2
Fuse
Diagnostics
bit S 1
Fuse
15.1.6.2 Filter Module
750-624/020-002, -626/020-002
The Filter Module 750-624/020-002 and 750-626/020-002 equipped with surge
suppression for the field side power supply have a total of 8 bits in both the Input
and Output Process Image.
Table 262: Filter Modules 750-624/020-002, 750-626/020-002
Input Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0V_MA
0V_PA
24V_MA
24V_PA
not used
PWR_DIAG
not used
VAL
Output Process Image
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
not used
not used
not used
not used
not used
not used
not used
GFT
15.1.6.3 Binary Space Module
750-622
