180 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.4.11 “Ethernet” > “Switch Configuration” Submenu
This submenu contains the settings for the Switch configuration.
Table 130: “Networking” > “Ethernet” > “Switch Configuration” Submenu
Submenu
Submenu Item / Explanation
0. Back to …
Back to the higher-level menu
1. Network interfaces
Enable or disable the switch.
0. Back to …
Back to the higher-level menu
1. Separated
Each interface is operated with its
own IP address.
2. Switched
Both interfaces are operated with one
IP address.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
7.8.2.4.12 “Ethernet” > “Ethernet Ports” Submenu
This submenu contains other submenus with settings for the ETHERNET
interfaces.
Table 131: “Networking” > “Ethernet” > “Ethernet Ports” Submenu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. Interface X1
Opens a submenu with settings for the X1 interface
2. Interface X2
Opens a submenu with settings for the X2 interface
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
