WAGO PFC100 - Reset Button; Figure 12: Reset Button

WAGO-I/O-SYSTEM 750 Device Description 39
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
3.5.3 Reset Button
Figure 12: Reset Button
The Reset button is installed behind drilling to prevent operating errors. It is a
shortstroke button with a low actuating force of 1.1 N … 2.1 N (110 gf … 210 gf).
The button can be actuated using a suitable object (e.g., pen).
You can initiate different functions using the Reset button depending on the
position of the mode selector:
• Temporarily set a fixed IP address (“Fixed IP Address” mode, see section
“Commissioning” > “Setting an IP Address” > “Temporarily Setting a Fixed
IP Address”)
• Perform a software reset (restart, see section “Commissioning” > “Initiating
Reset Functions” > “Software Reset”)
• Restore factory setting (factory reset, see section “Service” > “Firmware
Changes” > “Factory Reset”)
