130 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.1.19 “Firmware Backup” Page
You can find the controller data backup settings on the “Firmware Backup” page.
Table 65: “Firmware-Backup” WBM Page
Parameters
Explanation
Packages
You can select the data to be backed up here.
To do this, select the corresponding entries.
All
All data is backed up.
This selection is only enabled if the
memory card is selected as the
target.
PLC runtime
project
The PLC runtime project is backed
up.
Settings
The controller settings are backed
up.
System
The controller operating system is
backed up.
Destination
Select the storage location for the backup here.
Memory card
The data is written to the memory
card.
This selection only appears if a
memory card without system data is
inserted.
Network
The data are stored on the file
system and can then be
downloaded to the PC.
Activate “auto update
feature”
To start the automatic update when a memory card
with system data is inserted, select this button.
Note the firmware version!
Restoring the controller operating system (“System” selection) is only permissible
and possible if the firmware versions at the backup and restore times are
identical.
If necessary, skip restoring the controller operating system, or match the
firmware version of the controller to the firmware version of the backup time
beforehand.
Only one package may be copied to the network!
If you have specified “Network” as the storage location, only one package may
be selected for each storing process.
