WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Commissioning 173
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.3.5 “General Configuration” > “Home Dir On SD Card” Submenu
In this submenu, define if the home directory for the runtime system should be
moved to the memory card.
Table 117: “PLC Runtime” > “General Configuration” > “Home Dir On SD Card” Submenu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. Enable
The home directory is moved to the memory card.
2. Disable
The home directory is stored in the internal memory.
Insert a memory card before switching the home directory!
When moving the home directory to the memory card, insert a memory card
formatted to support file system. Only the first partition of a memory card can be
accessed at /media/sd and can be used as the home directory.
Perform a reset before switching the home directory!
Stop IEC-61131 applications in use before switching the home directory of the
runtime system.
Restore the device to its initial state using the “Reset” function. Any boot project
is deleted.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
