38 Device Description WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
3.5.2 Operating Mode Switch
Figure 11: Mode Selector Switch
</dg_
Table 11: Mode Selector Switch
Position
Actuation
Function
RUN
Latching
Normal operation
e!RUNTIME applications running.
STOP
Latching
Stop
All e!RUNTIME applications have stopped.
RESET
Spring-return
Reset warm start or
Reset cold start
(depending on length of actuation, see Section
“Starting” > “Initiating Reset Functions”)
</dg_
Other functions can also be initiated using the reset button.
