WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Appendix 293
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
Table 240: Serial Interface Modules 750-652, 753-652
Input and Output Process Image
Process
size
Offset
Byte Designation
Description
High Byte
Low Byte
8 bytes
0
C1/S1
C0/S0
Control/Status byte
C1/S1
Control/Status byte
C0/S0
1
D1
D0
Prozess data (6-46 bytes)
2
D3
D2
3
D5
D4
24 bytes*
4
D7
D6
…
11
D21
D20
48 bytes
12
D23
D22
…
23
D45
D44
*) Factory setting
15.1.5.6 Data Exchange Module
750-654, -654/000-001
The Data Exchange modules have a total of 4 bytes of user data in both the Input
and Output Process Image. The following tables illustrate the Input and Output
Process Image, which has a total of 2 words mapped into each image.
Word alignment is applied.
Table 241: Data Exchange Module 750-654, -654/000-001
Input and Output Process Image
Offset
Byte Designation
Description
High Byte
Low Byte
0
D1
D0
Data bytes
1
D3
D2
15.1.5.7 SSI Transmitter Interface Modules
750-630, and the variations /000-001, -002, -006, -008, -009, -011, -012, -013
The process image of the / 003-000-variants depends on the parameterized
operating mode!
The operating mode of the configurable /003-000 I/O module versions can be
set. Based on the operating mode, the process image of these I/O modules is
then the same as that of the respective version.
The above SSI Transmitter Interface modules have a total of 4 bytes of user data
in the Input Process Image, which has 2 words mapped into the image.
Word alignment is applied.
