WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Commissioning 193
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
7.8.2.8 “Package Server” Menu
This menu contains other submenus with functions for firmware backup and
restore, as well as information and setting options for the current system partition.
Table 145: “Package Server” Menu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. Firmware Backup
Opens a submenu with functions for the firmware
backup
2. Firmware Restore
Opens a submenu with functions for the firmware
restore
3. System Partition
Opens a submenu with information and setting
options for the current system partition
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
7.8.2.8.1 “Package Server” > “Firmware Backup” Submenu
This submenu contains a selection option for the data to be saved.
The submenu only appears if a memory card is inserted that does not contain a
bootable system. Otherwise, a message is displayed.
Table 146: “Package Server” > “Firmware Backup” Menu
Menu Item
Explanation
0. Back to …
Back to the higher-level menu
1. All
All data is saved.
2. PLC Runtime project
The PLC runtime project is saved.
3. Settings
The controller settings are saved.
4. System
The controller operating system is saved.
To make a selection, choose the appropriate menu item.
To return to the higher-level menu, press [Q].
You are taken to the following submenu after making the selection.
