WAGO PFC100 User Manual

WAGO-I/O-SYSTEM 750 Device Description 37
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
3.5 Operating Elements
3.5.1 Address Selection Switch
Figure 10: Address Selection Switch (here setting “0”)
Table 10: Significance of the Address Values of the Address Selection Switch
Address value
Explanation
0
The IP parameters are configured via the settings in the Web-
Based Management (WBM), Console-Based Management
(CBM) or by the factory settings.
1 … 254
A fixed IP address is assigned. The IP address consists of the
network address and the set address value. The network
address can be configured from the CBM or WBM and is
192.168.1 by default.
255
The DHCP protocol is used to configure the IP parameters.
