34
Devi
ce Description
WAGO-I/O-SYS
TEM 750
750
-
8100
PFC100; 2E
TH; ECO
Manual
Version 1.6.0, v
alid from F
W
Versi
on 03.02.02(14)
3.4
Display Elemen
ts
3.4.1
Fieldbus/Sy
stem Indicating Elements
Figure 7: Indicating elements for fieldbus/system
Table 7
:
Legend for Figure
“
Fieldbus/System Indicating Elements
”
Designation
Color
Description
SYS
Red/Green/
Orange/Off
System status
RUN
Red/Green/
Orange/O
ff
PLC program sta
t
us
I/O
Red/Green/
Orange/Off
Local bus status
MS
Red/Green/
Orange/Off
Module status
NS
Red/Green/
Orange/Off
Without function
USR
Red/Green/
Orange/Off
User LED, program
mable using
function
blocks from the
WAGO libraries
to control the
LEDs
33
35
