7.8.1.13.3 “Add New User Filter” Group
You can enter 10 filters.
You only have to enter values in the fields that are to be set for the filter. At least
one value must be entered, all other fields can remain empty.
Table 57: WBM “Configuration of User Filter” Page – “Add New User Filter” Group
Parameters
Explanation
Policy
Select here whether the network devices is to be
allowed or excluded by the filter.
Allow
The network device is permitted.
Drop
The network device is excluded.
Source IP address
Enter here the source IP address for the new filter
entry.
Source netmask
Enter here the source network mask for the new
filter entry.
Source port
Enter here the source port address for the new filter
entry.
Destination IP address
Enter here the destination IP address for the new
filter entry.
Destination subnet mask
Enter here the destination network mask for the new
filter entry.
Destination port
Enter the destination port number for the new filter
entry.
Protocol
Enter here the permitted protocols for the new filter.
TCP
The TCP service is permitted.
UDP
The UDP service is permitted.
Input interface
Enter here the permitted interfaces for the new filter.
X1
The X1 interface is permitted.
X2
The X2 interface is permitted.
VPN
The VPN interface is permitted.
To accept the new filter click [Add]. The change is effective immediately.
