136 Commissioning WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
</dg_
7.8.1.23 “Software Uploads” Page
The settings for a device update are shown on the “Software Uploads” page.
7.8.1.23.1 “Upload New Software” Group
Table 69: WBM “Software Uploads” Page – “Upload New Software” Group
Parameter
Explanation
Software Files
You can select fieldbus software, program licenses
and update scripts, for example, for transfer from a
PC to the controller.
To select a file on the PC, click the [Browse] button.
To transfer the selected file to the controller, click [Start Upload] button.
7.8.1.23.2 “Activate New Software” Group
Table 70: WBM “Software Uploads” Page – “Activate New Software” Group
Parameter
Explanation
Software File
This shows the file name of the transferred software
package. If no new uploaded software package is
present on the controller, the message “No upload
file exists” is displayed.
Action
Select here the action required.
Activate
The transferred software package is
activated.
Force
(Manual
reboot
afterward
s needed)
Installs a transferred software package
that cannot be activated with “Activate.”
Required for activating a controller
reboot.
The software package is activated on
reboot.
Discard
(delete
upload)
The transferred software package is
deleted again by the controller.
To perform the action, click the [Submit] button. The process starts immediately.
The file with the software package is deleted again after the installation is
completed or when the controller is restarted.
