WAGO PFC100 User Manual

304 Appendix WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
Table 256: Bluetooth
®
RF-Transceiver 750-644
Input and Output Process Image
Process
size
Offset
Byte Destination
Description
High Byte
Low Byte
12 bytes
0
-
C0/S0
not used
Control/status
byte
1
D1
D0
Mailbox (0, 6, 12 or 18 words)/
Process data (4 … 46 words)
…
…
…
5
D9
D8
24 bytes
6
D11
D10
…
…
…
11
D21
D20
48 bytes*
)
12
D23
D22
...
...
...
23
D45
D44
*) Factory Setting
15.1.5.17 Vibration Velocity/Bearing Condition Monitoring VIB I/O
750-645
The Vibration Velocity/Bearing Condition Monitoring VIB I/O has a total of 12
bytes of user data in both the Input and Output Process Image (8 bytes of
module data and 4 bytes of control/status). The following table illustrates the
Input and Output Process Image, which have 8 words mapped into each image.
Word alignment is applied.
Table 257: Vibration Velocity/Bearing Condition Monitoring VIB I/O 750-645
Input and Output Process Image
Offset
Byte Destination
Description
High Byte
Low Byte
0
-
C0/S0
not used
Control/status byte
(log. Channel 1,
Sensor input 1)
1
D1
D0
Data bytes
(log. Channel 1, Sensor input 1)
2
-
C1/S1
not used
Control/status byte
(log. Channel 2,
Sensor input 2)
3
D3
D2
Data bytes
(log. Channel 2, Sensor input 2)
4
-
C2/S2
not used
Control/status byte
(log. Channel 3,
Sensor input 1)
5
D5
D4
Data bytes
(log. Channel 3, Sensor input 3)
6
-
C3/S3
not used
Control/status byte
(log. Channel 4,
Sensor input 2)
7
D7
D6
Data bytes
(log. Channel 4, Sensor input 2)
