WAGO PFC100 User Manual

300 Appendix WAGO-I/O-SYSTEM 750
750-8100 PFC100; 2ETH; ECO
Manual
Version 1.6.0, valid from FW Version 03.02.02(14)
Output Process Image
Offset
Byte Designation
Note
High Byte
Low Byte
0
-
S
res.
Bit 0: Broadcast ON
Bit 1: Broadcast OFF
Bit 2: (1 button operation):
- short: Broadcast ON/OFF
- long: Broadcast dimming
brighter/darker
Bit 2: (2 buttons operation):
- short: Broadcast ON/OFF
- long: Broadcast dimming brighter
Bit 3: (1 button operation):
Broadcast ON/OFF
Bit 3: (2 buttons operation):
- short: Broadcast ON/OFF
- long: Broadcast dimming darker
Bit 4: Watchdog toggling (starting
from FW06 of the DALI Multi-
Master)
Bit 5…7: reserved
1
DA4…DA7
DA0…DA3
Bit pair for DALI address:
Bit 1 (1 button operation):
- short: DA switch ON/OFF
- long: dimming brighter/darker
Bit 1 (2 buttons operation):
- short: DA switch ON
- long: dimming brighter
Bit 2 (1 button operation):
DA switch ON/OFF
Bit 2 (2 buttons operation):
- short: DA switch OFF
- long: dimming darker
2
DA12…DA15
DA8…DA11
3
DA20…DA23
DA16…DA19
4
DA28…DA31
DA24…DA27
5
DA36…DA39
DA32…DA35
6
DA44…DA47
DA40…DA43
7
DA52…DA55
DA48…DA51
8
DA60…DA63
DA56…DA59
9
GA4…GA7
GA0…GA3
Bit pair for DALI group address:
Bit 1 (1 button operation):
- short: GA switch ON/OFF
- long: dimming brighter/darker
Bit 1 (2 buttons operation):
- short: GA switch ON
- long: dimming brighter
Bit 2 (1 button operation):
GA switch ON/OFF
Bit 2 (2 buttons operation):
- short: GA switch OFF
- long: dimming darker
10
GA12…GA15
GA8…GA11
11
Bit 8…15
Bit 0…7
Switch scene 0…15
DA = DALI address
GA = Group address
