7-46 Routine maintenance

2. Disconnect the ion chamber push-on connection.

3. On the left-hand side contact rail assembly, disconnect these parts:

• Focus 1 plate push-on connection.

• Ion chamber accelerating voltage push-on connection.

Focus 1 plate connection

Ion chamber accelerating

voltage connection
