Controls and connections on the rear of the instrument 1-15
– Source
– Analyzer
–Inlet 1
–Inlet 2
Vacuum connections
See “Vacuum pump maintenance” on page 7-3
Vacuum connections
Three vacuum connections are provided, for the Analyzer, Source, and Inlet 1
fore pumps.
Warning: To avoid toxic vapors, a suitable exhaust line must be fitted
to the fore pumps. If the exhaust is not correctly filtered,
environmental damage can occur.
Caution: Ensure that each rotary fore pump contains oil and has been
gas-ballasted before pumping.
